Aluminum-Disk

  • Aluminum circle alloy offers:

    1050, 1060, 1070, 1100, 1200, 3003 and 5052 alloy

  • Temper :

    O H12 H14 H16 H18 H22 H24 H26 H28

  • Thickness:

    0.3mm--10mm

  • Diameter:

    10-3000mm

  • Scrap rate:

    less than 3%

  • Processed:

    hot rolled or hot rolled or ( DC/CC)

Description Aluminum-disk
Aluminum circle alloy offers 1050, 1060, 1070, 1100, 1200, 3003,3004 and 5052 alloy
Temper  O H12 H14 H16 H18 H22 H24 H26 H28
Thickness 0.3mm--3.0mm
Diameter 10-6000mm
Scrap rate  less than 3%
Processed hot rolled or hot rolled or ( DC/CC)
Specification Aluminum disc for cookware
Alloy: 1050, 1060,1070, 1100, 1200,3003, 3004 etc.
Temper: O, H12, H22, H14, H24, H26, H18 etc.
Thickness: 0.2-3.0mm
Width: Up to 6000mm
Length: Up to 6000mm
Surface treatment: mill finished, anodized, embossed, PVC coated
Feature Price is much more competitive than that of other series.
Satisfy regular industrial process of stamping, drawing with good elongation, tensile strength and high formability.
Great plasticity, corrosion resistance, electrical conductiviy and termal conductivity.
Easy to be welded.
Easy to be pressure processed, extended and bent.
Application Sign board, Advertising board, Building decoration, Car body, Cooking utensil, Lamp holder, Fan leaf, Electrical part, Chemical instrument, Machined part, Deep-drawn or spinned part, Welded part, Heat exchanger, Clock surface, Decotation, Reflective instrument etc.
Alloy Chemical Component %≤
Si Fe Cu Mn Mg Cr Ni Zn Ti others Al
single total
1050 0.25 0.4 0.05 0.05 0.05

\

\

0.05 0.03 0.03

\

99.50
1060 0.25 0.35 0.05 0.03 0.03

\

\

0.05 0.03 0.03

\

99.60
1100 0.95 0.05-0.2 0.05

\

\

\

0.1

\

0.05 0.15 99.00
1200 1.00 0.05 0.05

\

\

\

0.1 0.05 0.05 0.15 99.00
 CC quality

• Recessed lighting                        • High bay industrial lighting

• Stress lighting                               •Traffic light reflectors

• Sports lighting.

 DC quality

Restaurant cookware, Rice cooker, Pressure cooker, Pan, Bakeware, Bread Makers, Road sign, Traffic sign, Auto parts, Appliance.
