Stranded Copper Conductor
Cross Link Polyethylene (XLPE)
Plain copper wire covered
Non Hygroscopic separator
Poly Vinyl Chloride (PVC)
Black
| Voltage Rating | 600V / 1000V |
| Temperature Limits | -15℃ to +90℃ |
| Minimum Bending Radius | As per cable manufacturer datasheet/td> |
| Installation Environment | Should not be installed at temperatures below 0℃ or above 60℃ |
| CCC CODE | CONDUCTOR SIZE | STRANDING | WEIGHT | OVERALL DIAMETER | GLAND SIZE |
| mm² | mm² | kg/km | mm | ||
| 4 SPLITCON | 4 | 7/0.85 | 206 | 9.6 | 205 |
| 6 SPLITCON | 6 | 7/1.04 | 281 | 11.4 | 20 |
| 10 SPLITCON | 10 | 7/1.35 | 394 | 11.4 | 20 |
| 16 SPLITCON | 16 | 7/1.70 | 583 | 14.6 | 25 |
| 25 SPLITCON | 25 | 7/2.14 | 843 | 18.7 | 32 |
| 35 SPLITCON | 35 | 7/2.52 | 1300 | 23 | 40 |
| NOMINAL CROSS SECTIONAL AREA (MM² ) | CLIPPED DIRECT AMPS | IN CONDUIT ON WALL AMPS | IN AIR AMPS |
| 4 | 41 | 37 | 42 |
| 6 | 50 | 46 | 51 |
| 10 | 68 | 63 | 70 |
| 16 | 99 | 88 | 100 |
| 25 | 130 | 117 | 135 |
| 35 | 120 | 110 | 129 |
| NOMINAL CROSS SECTIONAL AREA (MM2 ) | MAXIMUM DC RESISTANCE OF CONDUCTOR AT 20°C - PHASE OHMS/KM | MAXIMUM DC RESISTANCE OF CONDUCTOR AT 20°C - NEUTRAL OHMS/KM | MAXIMUM DC RESISTANCE OF CONDUCTOR AT 20°C - EARTH OHMS/KM |
| 4 | 4.61 | 4 | 4.80 |
| 6 | 3.08 | 3.15 | 3.15 |
| 10 | 1.83 | 1.90 | 1.90 |
| 16 | 1.15 | 1.20 | 1.20 |
| 25 | 0.727 | 0.76 | 0.76 |
| 35 | 0.524 | 0.55 | 0.55 |
